Silicon nitride ceramic substrate processing manufacturer

---

Q: Why does my power module always fail in high temperature, high humidity, or high vibration environments? Is there a material that can conduct heat, insulate, and withstand extreme working conditions?
A: Silicon nitride (Si ∝ N ₄) ceramic substrates are designed to solve such problems. It combines high thermal conductivity (70-90 W/m · K), excellent mechanical strength (flexural strength>800 MPa), low thermal expansion coefficient (≈ 3.2 × 10 ⁻⁶/K), and outstanding electrical insulation performance, and is widely used in fields such as new energy vehicles, rail transit, photovoltaic inverters, industrial power supplies, etc. that require high reliability. Choosing a professional silicon nitride ceramic substrate processing manufacturer means you will obtain a stable, efficient, and long-lasting electronic packaging foundation platform.

Product application: Empowering high-end power electronics systems
Silicon nitride ceramic substrate, as a key material for third-generation semiconductor packaging, has been deeply integrated into the following high-tech scenarios:
-New energy vehicles: DBC (direct bonding copper) or AMB (active metal brazing) substrates for SiC/GaN power modules, supporting 800V high-voltage platforms;
-Rail transit: IGBT modules in traction inverters need to withstand long-term vibration and temperature cycling;
-Photovoltaic and energy storage inverters: improve system efficiency and thermal management capabilities, and extend equipment lifespan;
-Industrial motor drive and high-frequency power supply: meet the dual requirements of heat dissipation and insulation at high switching frequencies.

Core strengths
Thermal conductivity (W/m · K): 70-90
Bending strength (MPa): 800-1000
Fracture toughness (MPa · m ¹/²): 6-8
Thermal expansion coefficient (× 10 ⁻⁶/K):~3.2
Key conclusion: Although aluminum nitride has higher thermal conductivity, its brittleness, high cost, and reliability are questionable; Silicon nitride achieves the best balance between comprehensive mechanical properties and thermal management capabilities, making it particularly suitable for dynamic loads and harsh environments.

Customized services: flexibly meet diverse engineering needs
We provide full chain silicon nitride ceramic substrate processing services, supporting:
-Size customization: Standard sizes such as 32 × 32mm, 50 × 50mm, 100 × 140mm, can also be processed up to a maximum of 150 × 150mm according to the drawing;
-Thickness range: 0.25mm, 0.38mm, 0.5mm, 0.635mm, 1.0mm, and other multiple options are available;
-Metalization process: supports DBC (copper thickness 100-300 μ m), AMB (copper or silver layer), and can be used for graphic etching;
-Surface treatment: integrated completion of subsequent processes such as polishing, sandblasting, laser marking, edge chamfering, etc;

What key issues are being addressed?

1. Thermal failure problem: High thermal conductivity effectively reduces chip junction temperature and increases power density;
2. Mechanical fracture risk: ultra-high fracture toughness to resist thermal stress and vibration impact;
3. Hidden dangers of insulation failure: volume resistivity>10 ¹⁴Ω· cm, withstand voltage>15 kV/mm;
4. CTE mismatch cracking: The thermal expansion coefficient is close to that of Si and SiC chips, reducing welding interface fatigue;

Customer Application Case (Anonymous)
-Case 1: A leading domestic electric drive enterprise uses our 0.38mm thick AMB silicon nitride substrate for 800V SiC inverters, reducing thermal resistance by 22% and increasing module life by 40%;
-Case 2: European rail transit suppliers imported 50 × 50mm DBC silicon nitride substrates, which showed no delamination after 5000 cycles of thermal shock at -40 ℃~150 ℃;
-Case 3: The photovoltaic inverter manufacturer replaced the original AlN substrate with Si ∝ N ₄ solution, resulting in a cost reduction of 18% and an increase in yield to 99.2%.

If you are looking for the ideal ceramic substrate solution for high-power, high reliability electronic systems, please feel free to contact us for free samples and customized technical solutions!
