Silicon nitride ceramics with low friction coefficient

---

Are you looking for an engineering ceramic material that combines low friction, high wear resistance, and extreme environmental adaptability? Are you troubled by the rapid wear of metal components in high-speed, high-temperature, or corrosive environments? Silicon nitride ceramics, with their extremely low friction coefficient and excellent comprehensive performance, are becoming an ideal choice to solve these challenges. This article will delve into how silicon nitride ceramics can meet your core needs through their unique characteristics – reducing energy consumption, extending component life, improving equipment reliability, and being suitable for various demanding application scenarios from bearings to semiconductor manufacturing.

What is silicon nitride ceramic?
Silicon nitride (Si ∝ N ₄) ceramics are an advanced structural ceramic material made through high-temperature sintering or reaction sintering processes. Its crystal structure endows it with a series of extraordinary physical and chemical properties, among which one of the most prominent features is its self-lubricating properties and extremely low friction coefficient (usually between 0.1-0.5, depending on the working conditions and paired materials), which allows it to operate stably under no lubrication or poor oil lubrication conditions.

Core advantage: Why choose silicon nitride ceramics with low friction coefficient?

1. Excellent tribological performance
   -Extremely low friction coefficient: When paired with steel, ceramics, or itself, the friction coefficient is much lower than most metals and traditional ceramics, effectively reducing energy loss and heat generation of moving parts.
   -High wear resistance: High hardness (HV10 ≥ 1400), extremely low wear rate, and service life 5-10 times longer than traditional bearing steel.
   -Self lubrication potential: Under specific conditions, a lubricating film can form on the surface, further reducing friction.
2. Excellent mechanical and thermal performance
   -High strength and toughness: High bending strength (up to 800MPa), and fracture toughness better than most engineering ceramics.
   -Excellent thermal stability: able to maintain strength at high temperatures above 1200 ℃, low coefficient of thermal expansion, and excellent thermal shock resistance.
   -Lightweight: The density is only 3.2-3.3 g/cm ³, about 40% of steel, which helps reduce the inertia of rotating parts.
3. Outstanding chemical stability
   -Resistant to corrosion from most acids, alkalis, and molten metals, with good oxidation resistance, suitable for harsh chemical environments.

Key application areas: What practical problems are solved?
The low friction properties of silicon nitride ceramics make them revolutionary materials for many high demand applications:
-High speed precision bearings: used for machine tool spindles, turbochargers, aviation engine accessories, etc., to solve problems such as temperature rise, wear, and lifespan at high speeds.
-Semiconductor manufacturing equipment: As a wafer handling robotic arm and vacuum chamber component, it provides high cleanliness, low particle precipitation, and plasma erosion resistance.
-Chemical and pump industry: mechanical seal rings, valve components, addressing sealing and wear resistance challenges in highly corrosive media.
-Automobiles and new energy vehicles: used for hybrid bearings, insulation components of electric drive systems, to assist in energy efficiency improvement and lightweighting.
-Food and medical equipment: meet the requirements of oil-free lubrication, corrosion resistance, and biocompatibility.

Specifications and customized services: meet your personalized needs
We provide comprehensive customized solutions for silicon nitride ceramic components:
-Size range: It can produce products ranging from millimeter level (such as ceramic ball diameter of φ 1mm) to several hundred millimeter level (such as large structural components).
-Shape complexity: Supports near net forming of complex shapes, including spheres, rollers, rings, and irregular structural components.
-Surface treatment: It can provide subsequent processing such as polishing (Ra ≤ 0.01 μ m) and coating (such as DLC) to further optimize friction performance.
-Accuracy control: The maximum dimensional tolerance can reach ISO standard tolerance level IT3, meeting the requirements of precision assembly.
-Material formula optimization: The formula can be adjusted according to specific applications (such as adding specific sintering aids) to balance mechanical, thermal, and tribological properties.

Customer Application Case (Anonymous)
-Case A: A certain international high-end machine tool manufacturer
-Problem: The spindle bearings experience rapid temperature rise and frequent lubrication and maintenance at ultra-high speeds, which affects machining accuracy and efficiency.
-Solution: Adopt the precision silicon nitride ceramic hybrid bearing ball provided by our company.
-Effect: The temperature rise of the bearing is reduced by 35%, the lubrication interval is extended by 3 times, and the overall life of the spindle is increased by more than 50%.
-Case B: Electric Drive Department of a New Energy Vehicle Enterprise
-Problem: The motor insulation bearings fail early in an electrically corrosive environment.
-Solution: Customized development of conductive silicon nitride ceramic insulation ring components.
-Effect: Completely eliminate the problem of electrical corrosion, ensure that the lifespan of components is the same as that of the motor, and assist in the successful mass production of platform models.
-Case C: A semiconductor equipment manufacturer
-Problem: The vacuum transfer robot arm generates trace particles during high-speed movement, contaminating the wafer.
-Solution: Adopt ultra-high cleanliness and low friction coefficient silicon nitride ceramic guide rails and bearings.
-Effect: The amount of particle precipitation is reduced by one order of magnitude, meeting the requirements of Class 1 cleanrooms, and the customer yield rate is significantly improved.

Silicon nitride ceramics with low friction coefficient are not only a breakthrough in material technology, but also a key partner for you to improve product performance and reliability. If you are seeking solutions to engineering challenges caused by wear, corrosion, high temperatures, or high speeds, please feel free to contact us immediately. Our technical team will provide you with free material selection consultation and sample testing services to jointly customize your exclusive high-performance solution.

Brudeze Ceramics supplies and sells a wide range of high-quality quartz glass, including alumina ceramics, zirconia ceramics, silicon nitride ceramics, aluminum nitride ceramics, silicon carbide ceramics, boron carbide ceramics, bioceramics, machinable ceramics, etc. We can meet the customization requirements of various ceramic products.
